- Lithium Battery DC Power,
- MC Step-Up Transformer,
- Tunable Load Impedance,
- Full Balance Circuit.
LP5.0 TBPS is a noise free phono stage

The phono stage most needs a fully balanced connection,
Balanced connection is the foundation of isolating background noise,
It is the key that has long been ignored by audiophile.


Guarantee of high-end sound

Specification

    Interface :

      INPUT : 3 * XLR balanced
      OUTPUT1 * XLR balanced

    Gain(@1kHz) :


    MM: 44dB
    MC: 10X=63dB, 20X=68dB


    RIAA EQ :

      - 0.03 ~ +0.05dB ( 20Hz to 20KHz )

    THD Ratio:

       MM: < 0.03% ( 20Hz to 20KHz )

    MC: < 0.2% ( 20Hz to 20KHz )

    Load Impedance:

       MM = 12K/15K/20K/25K/30K/35K/47K/100K/160K

    MC 10X= 120/150/200/250/300/350/470/1K/1.6K

    MC 20X= 30/38/50/63/75/88/118/250/400

    Input capacity:

    MM/MC = 100pF

    Battery:

    5200mAh-7.4V lithium battery

    Power adapter:

    DC 12V / 1A

    Power consumption:

    0.8 W

    Net Weight:

    5.8Kg

    Gross Weight:

    7.0Kg

    Net size:

    319 (W) x 306 (D) x 124 (H) mm

    Packing size

    529 (W) x 410 (D) x 214 (H) mm
